PSMN7R8-120ESQ Images
- Manufacturer: NXP
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: I2PAK
- Description: POWER FIELD-EFFECT TRANSISTOR, 7
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
PSMN7R8-120ESQ Specifications:
- MfrPart.: PSMN7R8-120ESQ
- Mfr: NXP USA Inc.
- Description: POWER FIELD-EFFECT TRANSISTOR, 7
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Bulk
- Series: -
- PartStatus: Active
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 120 V
- Current-ContinuousDrain(Id)@25°C: 70A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 10V
- RdsOn(Max)@IdVgs: 7.9mOhm @ 25A, 10V
- Vgs(th)(Max)@Id: 4V @ 1mA
- GateCharge(Qg)(Max)@Vgs: 167 nC @ 10 V
- Vgs(Max): ±20V
- InputCapacitance(Ciss)(Max)@Vds: 9.473 pF @ 60 V
- FETFeature: -
- PowerDissipation(Max): 349W (Tc)
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Through Hole
- SupplierDevicePackage: I2PAK
- PSMN7R8-120ESQ NXP, POWER FIELD-EFFECT TRANSISTOR, 7, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
PSMN7R8-120ESQ, NXP authentic parts in stock from NXP authorized distributors, order today, can ship immediately.
