PSMN3R2-30YLC,115 Images
- Manufacturer: NXP
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: LFPAK56, Power-SO8
- Description: ELEMENT, NCHANNEL, SILICON, MOSF
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
PSMN3R2-30YLC,115 Specifications:
- MfrPart.: PSMN3R2-30YLC,115
- Mfr: NXP USA Inc.
- Description: ELEMENT, NCHANNEL, SILICON, MOSF
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Bulk
- Series: -
- PartStatus: Active
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 30 V
- Current-ContinuousDrain(Id)@25°C: 100A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 4.5V, 10V
- RdsOn(Max)@IdVgs: 3.5mOhm @ 25A, 10V
- Vgs(th)(Max)@Id: 1.95V @ 1mA
- GateCharge(Qg)(Max)@Vgs: 29.5 nC @ 10 V
- Vgs(Max): ±20V
- InputCapacitance(Ciss)(Max)@Vds: 2.081 pF @ 15 V
- FETFeature: -
- PowerDissipation(Max): 92W (Tc)
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: LFPAK56, Power-SO8
- PSMN3R2-30YLC,115 NXP, ELEMENT, NCHANNEL, SILICON, MOSF, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
PSMN3R2-30YLC,115, NXP authentic parts in stock from NXP authorized distributors, order today, can ship immediately.
