PMN25UN,115 Images
- Manufacturer: NXP
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: SC-74
- Description: MOSFET N-CH 20V 6A 6TSOP
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
PMN25UN,115 Specifications:
- MfrPart.: PMN25UN,115
- Mfr: NXP USA Inc.
- Description: MOSFET N-CH 20V 6A 6TSOP
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: -
- PartStatus: Obsolete
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 20 V
- Current-ContinuousDrain(Id)@25°C: 6A (Ta)
- DriveVoltage(MaxRdsOnMinRdsOn): 1.8V, 4.5V
- RdsOn(Max)@IdVgs: 27mOhm @ 6A, 4.5V
- Vgs(th)(Max)@Id: 1V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 10 nC @ 4.5 V
- Vgs(Max): ±8V
- InputCapacitance(Ciss)(Max)@Vds: 470 pF @ 10 V
- FETFeature: -
- PowerDissipation(Max): 530mW (Ta), 6.25W (Tc)
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: SC-74
- PMN25UN,115 NXP, MOSFET N-CH 20V 6A 6TSOP, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
PMN25UN,115, NXP authentic parts in stock from NXP authorized distributors, order today, can ship immediately.
