PDTC143ET,235 Images
- Manufacturer: NXP
- Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single, Pre-Biased Package/Case: TO-236-3, SC-59, SOT-23-3
- Description: PDTC143E - NPN RESISTOR-EQUIPPED
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
PDTC143ET,235 Specifications:
- MfrPart.: PDTC143ET,235
- Mfr: NXP Semiconductors
- Description: PDTC143E - NPN RESISTOR-EQUIPPED
- Product Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single, Pre-Biased
- Package: Bulk
- Series: -
- PartStatus: Active
- TransistorType: NPN - Pre-Biased
- Current-Collector(Ic)(Max): 100 mA
- Voltage-CollectorEmitterBreakdown(Max): 50 V
- Resistor-Base(R1): 4.7 kOhms
- Resistor-EmitterBase(R2): 4.7 kOhms
- DCCurrentGain(hFE)(Min)@IcVce: 30 @ 10mA, 5V
- VceSaturation(Max)@IbIc: 150mV @ 500µA, 10mA
- Current-CollectorCutoff(Max): 1µA
- Frequency-Transition: -
- Power-Max: 250 mW
- MountingType: Surface Mount
- Package/Case: TO-236-3, SC-59, SOT-23-3
- PDTC143ET,235 NXP, PDTC143E - NPN RESISTOR-EQUIPPED, Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single, Pre-Biased
PDTC143ET,235, NXP authentic parts in stock from NXP authorized distributors, order today, can ship immediately.
