PDTC115EMB,315 Images
- Manufacturer: NXP
- Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single, Pre-Biased Package/Case: 3-XFDFN
- Description: PDTC115E - NPN RESISTOR-EQUIPPED
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
PDTC115EMB,315 Specifications:
- MfrPart.: PDTC115EMB,315
- Mfr: NXP Semiconductors
- Description: PDTC115E - NPN RESISTOR-EQUIPPED
- Product Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single, Pre-Biased
- Package: Bulk
- Series: -
- PartStatus: Active
- TransistorType: NPN - Pre-Biased
- Current-Collector(Ic)(Max): 20 mA
- Voltage-CollectorEmitterBreakdown(Max): 50 V
- Resistor-Base(R1): 100 kOhms
- Resistor-EmitterBase(R2): 100 kOhms
- DCCurrentGain(hFE)(Min)@IcVce: 80 @ 5mA, 5V
- VceSaturation(Max)@IbIc: 150mV @ 250µA, 5mA
- Current-CollectorCutoff(Max): 1µA
- Frequency-Transition: 230 MHz
- Power-Max: 250 mW
- MountingType: Surface Mount
- Package/Case: 3-XFDFN
- PDTC115EMB,315 NXP, PDTC115E - NPN RESISTOR-EQUIPPED, Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single, Pre-Biased
PDTC115EMB,315, NXP authentic parts in stock from NXP authorized distributors, order today, can ship immediately.
